The ZING Battery Model 12Z-IN-G200 Wall Mounted is a premium, high-capacity lithium battery engineered for residential and commercial energy storage applications requiring maximum runtime. This flagship wall-mounted design combines ZING's advanced lithium technology with a sleek, space-saving form factor, delivering an impressive 2.56 kWh of usable energy in an elegant package ideal for home and business installations.
With its powerful 12.8V 200Ah configuration, this battery provides double the capacity of standard 100Ah models, making it perfect for larger home solar systems, extended inverter backup, commercial UPS applications, and serious off-grid energy projects. The wall-mountable design saves valuable floor space while delivering the reliability and performance of advanced lithium iron phosphate (LiFePO₄) technology.
Ultra-High 200Ah Capacity: Provides 2.56 kWh of usable energy—double the capacity of standard 100Ah models—for maximum runtime in residential and commercial applications .
Space-Saving Wall Mount Design: Elegant, compact form factor designed for easy installation on walls, saving valuable floor space in homes, garages, utility rooms, and commercial spaces .
12.8V Nominal Voltage: Standard 12V configuration compatible with a wide range of inverters, solar charge controllers, and battery chargers .
Advanced Lithium Iron Phosphate (LiFePO₄) Technology: Utilizes the safest and most stable lithium chemistry available, offering superior thermal stability, exceptional cycle life, and environmental friendliness .
Exceptional 6000+ Cycle Life: Engineered for 6000+ deep discharge cycles at 80% depth of discharge, delivering 10-15 years of reliable service .
Built-In Intelligent BMS: Advanced Battery Management System with comprehensive protection against overcharge, over-discharge, overcurrent, short circuit, high/low temperature, and active cell balancing .
High Discharge Current: Supports continuous discharge up to 200A (2.56kW) and peak discharge up to 300A (3.84kW) for demanding loads .
Plug-and-Play Installation: Designed for easy integration with residential solar systems, inverters, and chargers—minimal configuration required .
Zero Maintenance: No water topping, no acid leaks, no regular maintenance required—truly fit-and-forget operation .
Lightweight & Compact: Significantly lighter than equivalent lead-acid batteries, making wall mounting simple and secure .
Scalable Design: Multiple batteries can be connected in parallel for larger capacity systems up to multiple tens of kilowatt-hours .
Quiet Operation: No noise, no fumes, no moving parts—perfect for indoor installation .
Environmentally Friendly: Clean energy technology with no heavy metals or toxic materials, fully recyclable .
| Specification | Detail |
|---|---|
| Model Number | 12Z-IN-G200 Wall Mounted |
| Brand | ZING Battery |
| Mounting Type | Wall Mountable |
| Nominal Voltage | 12.8V |
| Capacity | 200Ah |
| Energy Capacity | 2.56 kWh |
| Battery Type | Lithium Iron Phosphate (LiFePO₄) |
| Cycle Life | 6000+ cycles @ 80% DoD |
| Design Life | 10-15 years typical |
| Built-in BMS | Yes (Overcharge, Over-discharge, Overcurrent, Short Circuit, Temperature, Active Cell Balancing) |
| Charge Voltage | 14.4V ±0.2V |
| Discharge Cut-off | 10.8V ±0.2V |
| Max Continuous Charge Current | 100A |
| Max Continuous Discharge Current | 200A |
| Peak Discharge Current | 300A (for 3-5 seconds) |
| Max Continuous Power | 2.56 kW |
| Peak Power | 3.84 kW |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Operating Temperature (Discharge) | -20°C ~ 60°C |
| Storage Temperature | -10°C ~ 35°C |
| Enclosure Material | Fire-retardant ABS / Metal (depending on variant) |
| Terminal Type | Heavy-duty easy-connect terminals |
| Protection Class | IP54 (dust and splash resistant) |
| Maintenance | Zero maintenance |
| Certifications | CE, RoHS, UN38.3 (transport certified) |
| Installation | Wall mounted (heavy-duty mounting brackets included) |
The ZING Battery Model 12Z-IN-G200 Wall Mounted is ideally suited for:
Home solar systems requiring maximum backup time
Large off-grid solar installations
Solar self-consumption optimization
Energy storage for time-of-use rate management
Whole-home backup power
Whole-home inverter backup systems
Essential and non-essential load coverage
Refrigeration and freezer protection
Medical device backup power
Home office and computer systems
Small business backup power
Retail point-of-sale systems
Security and surveillance systems
Emergency lighting for commercial spaces
Telecom equipment backup
High-capacity uninterruptible power supplies
Server and network equipment backup
Medical facility emergency power
Laboratory equipment protection
Larger off-grid cabins and vacation homes
RV and camper van conversions
Marine and boat applications
Tiny home power systems
Workshop and tool power
Telecom base station backup
Remote sensor and monitoring stations
Weather stations
Traffic monitoring systems
The 200Ah configuration provides a significant upgrade over standard batteries, delivering:
Double the Runtime: Keep your critical loads running twice as long during outages compared to 100Ah batteries
Fewer Parallel Connections: Higher capacity dramatically reduces the number of parallel batteries needed
Simpler Installation: Less wiring, fewer connections, lower complexity, higher reliability
Better Value: More capacity per installation dollar compared to multiple smaller batteries
Future-Ready: Built for expanding energy needs and system upgrades
| Parameter | ZING 12Z-IN-G200 Lithium | Lead-Acid Battery (200Ah) |
|---|---|---|
| Usable Capacity | 90-100% (2.56 kWh usable) | 50% (1.28 kWh usable from 200Ah) |
| Cycle Life | 6000+ cycles (10-15 years) | 300-500 cycles (2-3 years) |
| Weight | Lightweight (easy wall mount) | Heavy (120-150+ lbs) |
| Maintenance | Zero | Regular watering, cleaning required |
| Installation | Wall mountable (space-saving) | Floor standing only |
| Depth of Discharge | 80-100% recommended | 50% max recommended |
| Discharge Power | 2.56 kW continuous | Limited by capacity |
| Total Cost of Ownership | Lowest | Very high (frequent replacement) |
2.56 kWh Usable Energy: Double the capacity of standard 100Ah models
6000+ Cycle Life: Replace your batteries once every 10-15 years instead of every 2-3 years
200A Continuous Discharge: Power demanding loads up to 2.56kW
Double the Usable Power: Access 100% of rated capacity vs. only 50% with lead-acid
70% Lighter: Easy to install and secure on walls
Zero Maintenance: No watering, no cleaning, no acid spills
Safe for Indoor Use: No fumes, no venting required, no moving parts
Smart BMS: Automatic protection and active cell balancing for maximum safety
IP54 Protection: Dust and splash resistant for versatile installation locations
Scalable Design: Connect multiple units for up to 10-20 kWh+ systems
The ZING 12Z-IN-G200 Wall Mounted comes complete with heavy-duty mounting brackets and hardware for secure wall installation. The compact, elegant design allows for installation in:
Utility rooms and basements
Garages and workshops
Server rooms and telecom closets
RV compartments and boat cabins
Tiny homes and off-grid structures
Commercial storage areas
Solar equipment rooms
Installation Requirements:
Solid wall (studs or concrete) capable of supporting the battery weight
Adequate ventilation (minimal required for lithium)
Access to compatible inverter/charger
Proper cable sizing for expected currents (up to 200A)
Overcurrent protection (fuse or breaker) on DC circuit
Compliance with local electrical codes
Parallel Configuration:
Up to 4 batteries can be connected in parallel for systems up to 10.24 kWh total capacity.
The ZING 12Z-IN-G200 Wall Mounted is compatible with:
Solar Charge Controllers: Works with MPPT and PWM controllers configured for lithium batteries (14.4V absorption)
Inverters: Compatible with most 12V inverters up to 3000W continuous
Battery Chargers: Requires lithium-compatible charger (14.4V absorption, 13.8V float)
UPS Systems: Can replace lead-acid batteries in compatible UPS units
DC-DC Chargers: Ideal for RV and marine charging from alternator
Battery Monitors: Compatible with Victron, BMV, and other monitoring systems
DIY Projects: Perfect for custom energy storage systems
