The ZING Battery Model 12Z-IN-G100 Rack Mounted is a professional-grade lithium battery engineered for telecommunications, data centers, industrial applications, and commercial energy storage requiring standard 19-inch rack integration. This rack-mountable design combines ZING's advanced lithium technology with a standardized form factor, delivering 1.28 kWh of reliable energy in a space-efficient package ideal for server rooms, telecom shelters, and industrial cabinets.
With its 12.8V 100Ah configuration and 19-inch rack form factor, this battery is perfect for telecom backup systems, rack-mounted UPS applications, server room power protection, and commercial energy storage where standard rack integration is required. The rack-mountable design optimizes space utilization while delivering the reliability and performance of advanced lithium iron phosphate (LiFePO₄) technology.
Standard 19-Inch Rack Mount Design: Industry-standard form factor designed for seamless integration into 19-inch server racks, telecom racks, and industrial equipment cabinets .
12.8V 100Ah Capacity: Provides 1.28 kWh of usable energy for telecommunications, data center, and commercial applications .
Advanced Lithium Iron Phosphate (LiFePO₄) Technology: Utilizes the safest and most stable lithium chemistry available, offering superior thermal stability, exceptional cycle life, and environmental friendliness .
Exceptional 4000+ Cycle Life: Engineered for 4000+ deep discharge cycles at 80% depth of discharge, delivering 8-10 years of reliable service .
Built-In Intelligent BMS: Advanced Battery Management System with comprehensive protection against overcharge, over-discharge, overcurrent, short circuit, high/low temperature, and cell balancing .
Plug-and-Play Installation: Designed for easy integration with telecom power systems, rack-mounted UPS units, and DC power systems .
Zero Maintenance: No water topping, no acid leaks, no regular maintenance required—ideal for remote and unattended installations .
Space-Efficient Design: Optimized for high-density rack installations, maximizing energy storage per rack unit .
Scalable Configuration: Multiple batteries can be connected in parallel for larger capacity systems within the same rack .
Quiet Operation: No noise, no fumes, no moving parts—perfect for indoor rack installations .
Environmentally Friendly: Clean energy technology with no heavy metals or toxic materials, fully recyclable .
| Specification | Detail |
|---|---|
| Model Number | 12Z-IN-G100 Rack Mounted |
| Brand | ZING Battery |
| Mounting Type | 19-inch Rack Mount (2U/3U typical) |
| Nominal Voltage | 12.8V |
| Capacity | 100Ah |
| Energy Capacity | 1.28 kWh |
| Battery Type | Lithium Iron Phosphate (LiFePO₄) |
| Cycle Life | 4000+ cycles @ 80% DoD |
| Design Life | 8-10 years typical |
| Built-in BMS | Yes (Overcharge, Over-discharge, Overcurrent, Short Circuit, Temperature, Cell Balancing) |
| Charge Voltage | 14.4V ±0.2V |
| Discharge Cut-off | 10.8V ±0.2V |
| Max Continuous Charge Current | 50A |
| Max Continuous Discharge Current | 100A |
| Peak Discharge Current | 150A (for 3-5 seconds) |
| Operating Temperature (Charge) | 0°C ~ 55°C |
| Operating Temperature (Discharge) | -20°C ~ 60°C |
| Storage Temperature | -10°C ~ 35°C |
| Enclosure Material | Heavy-duty metal rackmount chassis |
| Rack Size | Standard 19-inch rack (2U height typical) |
| Terminal Type | Heavy-duty front-panel terminals |
| Protection Class | IP20 (indoor rack installation) |
| Maintenance | Zero maintenance |
| Certifications | CE, RoHS, UN38.3 (transport certified) |
| Installation | 19-inch rack mount (rack ears included) |
The ZING Battery Model 12Z-IN-G100 Rack Mounted is ideally suited for:
Telecom base station backup power
Central office and exchange equipment
Microwave and radio transmission sites
Fiber optic network equipment
Remote telecom shelters
Rack-mounted UPS backup systems
Server and network equipment protection
Storage area network (SAN) backup
Critical IT infrastructure
PLC and industrial controller backup
SCADA system power protection
Process control equipment
Remote monitoring stations
Point-of-sale system backup
Security and surveillance systems
Emergency communication equipment
Building management systems
Traffic management systems
Railway signaling equipment
Airport navigation aids
Toll collection systems
12V DC distribution systems
Network equipment power backup
Audio/video rack systems
Broadcast equipment
The 19-inch rack mount design offers significant advantages for professional installations:
Standardized Integration: Seamlessly fits into existing 19-inch racks and cabinets
Space Optimization: Maximizes energy density per rack unit
Professional Appearance: Clean, organized installation for equipment rooms
Easy Service Access: Front-panel terminals and indicators for convenient maintenance
Scalable Architecture: Multiple units stack neatly in the same rack
| Parameter | ZING 12Z-IN-G100 Lithium | Lead-Acid Battery |
|---|---|---|
| Usable Capacity | 90-100% (1.28 kWh usable) | 50% (0.64 kWh usable from 100Ah) |
| Cycle Life | 4000+ cycles (8-10 years) | 300-500 cycles (2-3 years) |
| Weight | Lightweight (rack mountable) | Heavy (difficult to rack mount) |
| Maintenance | Zero | Regular watering, cleaning required |
| Rack Installation | Standard 19-inch design | Requires custom trays/shelves |
| Temperature Tolerance | Wide operating range | Sensitive to temperature |
| Total Cost of Ownership | Lowest | High (frequent replacement) |
1.28 kWh Reliable Power: Dependable backup for critical equipment
4000+ Cycle Life: Replace batteries once a decade instead of every 2-3 years
Zero Maintenance: Perfect for remote and unattended installations
Standard Rack Form Factor: No custom mounting required
Front-Panel Access: Easy monitoring and connection
Smart BMS: Automatic protection and monitoring
Scalable Design: Add capacity within the same rack
Proven Reliability: Engineered for continuous duty applications
The ZING 12Z-IN-G100 Rack Mounted comes complete with rack ears and mounting hardware for standard 19-inch rack installation. The professional design allows for installation in:
19-inch telecom racks and cabinets
Server racks and data center enclosures
Industrial control cabinets
Network equipment racks
Broadcast equipment racks
UPS equipment cabinets
Rack Space Requirements:
Typically occupies 2U or 3U of rack height (verify with specifications)
Standard 19-inch rack width
Depth compatible with most rack configurations
Installation Requirements:
Standard 19-inch rack with adequate weight capacity
Proper ventilation within rack (minimal required for lithium)
Access to compatible power system
Proper cable sizing for expected currents
Overcurrent protection on DC circuit
Compliance with local electrical and telecom standards
Parallel Configuration:
Multiple batteries can be connected in parallel within the same rack for higher capacity systems.
The ZING 12Z-IN-G100 Rack Mounted is compatible with:
Telecom Power Systems: -48V systems (requires series configuration) or 12V distribution
Rack-Mounted UPS: Compatible with 12V DC input UPS units
Rectifier Systems: Works with telecom rectifiers configured for lithium
Battery Chargers: Requires lithium-compatible charger (14.4V absorption)
DC Power Distribution: Standard 12V distribution panels
Battery Monitors: Compatible with professional monitoring systems
