UNI-T UDP6720 60V/5A 100W Programmable DC Power Supply

Overview

The UNI-T UDP6720 is a versatile, single-channel programmable DC power supply designed for laboratory use, electronics development, and educational applications . It delivers a wide output range of 0-60V and 0-5A with a maximum power of 100W in a compact, lightweight package .

Key Features

• High-Resolution Output: Offers precise voltage and current control with a programming resolution of 10mV and 1mA .

• 2.8" TFT LCD Display: Features a clear, full-color screen for easy monitoring of voltage, current, and power .

• Digital Control: Fully digitally controlled with low ripple and noise, ensuring stable power for sensitive circuits .

• Advanced Protection: Equipped with Over Voltage Protection (OVP), Over Current Protection (OCP), and Over Temperature Protection (OTP) to safeguard connected devices .

• Remote Sensing: Includes a remote compensation function to ensure accurate voltage delivery at the load, compensating for drops in long test leads .

• Automation Functions: Built-in List and Delayer modes allow for the programming of complex test sequences and timed power cycles .

Connectivity

Supports remote control and integration into automated test systems via an RS232 interface, utilizing SCPI or Modbus protocols .

Applications

Ideal for circuit debugging, battery charging, education labs, and general R&D testing where a single, high-precision DC source is required .

Key Specifications

• Output Voltage: 0 – 60V DC

• Output Current: 0 – 5A

• Max Power: 100W

• Display: 2.8" TFT LCD

• Resolution: 10mV / 1mA

• Protection: OVP, OCP, OTP

• Interface: RS232

• Dimensions: 87 x 255 x 174 mm

• Weight: 2.56 kg

The UNI-T UDP6720: Compact, precise, and programmable power for your bench.
