Large HMI Touchscreen:
Intuitive interface for real-time monitoring of system status, PV input, and load management.
-
Dual Output Design:
Supports smart load management, separating critical and non-critical loads for optimized energy distribution.
-
High PV Input Capacity:
Maximum PV input current of 30A per channel with a wide voltage range of 90VDC – 450VDC, accommodating various solar panel configurations.
-
Visual Status Indicators:
RGB lights provide clear indication of system operation and alerts.
-
Connectivity & Monitoring:
-
Built-in Wi-Fi for mobile monitoring (Android/iOS apps)
-
USB On-the-Go (OTG) support for data transfer and firmware upgrades
-
Reserved BMS communication port (RS485, CAN-BUS, RS232)
-
Reliable & Easy Maintenance:
-
Replaceable fan design for simplified maintenance
-
Battery-independent operation
-
Configurable AC/PV output timers and prioritization
-
Compatible with utility mains or generator input
-
Additional Features:
-
Built-in anti-dust kit
-
Integrated DC output for fans, LED bulbs, routers, and other low-voltage devices
-
Parallel operation of up to 6 units for scalable energy solutions
