High Efficiency:
Achieves up to 98.6% efficiency, maximizing energy conversion from your solar array.
-
Wide Voltage Range:
Supports 200V to 1100V, allowing flexibility with various PV panel configurations.
-
Multiple MPPT Inputs:
3 independent MPPT channels optimize energy harvesting from different sections of the solar array.
-
High Power Output:
Rated at 30,000 W, delivering stable AC output with unity power factor, ideal for commercial-scale applications.
-
Weatherproof Design:
IP65-rated for reliable outdoor operation, protecting against dust and water ingress.
-
Connectivity & Monitoring:
Built-in Wi-Fi and RS485 for remote monitoring and system management.
-
Comprehensive Safety Features:
Includes over-voltage, over-current, over-temperature, and short-circuit protections for safe operation.
-
Wide Operating Temperature Range:
Functions reliably between -25°C and +60°C.
-
Robust Construction:
-
Transformerless topology for high efficiency
-
Active cooling system for thermal stability
-
Dimensions: 670 × 580 × 270 mm
-
Weight: 42 kg
