Scalable Parallel Operation – Connect up to 10 units in on-grid/off-grid setups
-
AC Coupling Ready – Retrofit existing grid-tied systems to hybrid without changing infrastructure
-
48V Battery Support – Compatible with lead-acid and lithium-ion batteries, dual inputs for redundancy or expansion
-
User-Friendly Interface – Color touch LCD in IP65-rated enclosure, suitable for indoor/outdoor installation
-
Programmable Battery Scheduling – Six configurable time slots for customized charge/discharge cycles
-
Diesel Generator Integration – Efficiently stores energy from DG backup sources in remote or unstable areas
-
High Efficiency & Clean Output – 97.6% peak efficiency, >99% MPPT accuracy, <0.5% DC ripple
-
Heavy-Duty Build & Air Cooling – Operates reliably from -40°C to +60°C with intelligent thermal regulation
-
Comprehensive Protections – Includes surge, polarity, overcurrent, short-circuit, thermal, insulation monitoring, and RCD safeguards
-
Smart Monitoring & Communication – Supports RS485/RS232/CAN and optional Wi-Fi, Bluetooth, 4G, LAN remote monitoring
-
Global Compliance & Warranty – 5-year warranty, compliant with IEC, EMC, and OVC safety standards
